Overview
Key Feature:
Deployment Indoor
Wi-Fi generation Wi-Fi 7 (802.11be)
Wi-Fi radios Triple 4×4
Radio configuration options 2.4 GHz + 5 GHz + 6 GHz or 5 GHz + 5 GHz + 6 GHz or 5 GHz + 6 GHz + 6 GHz
Max bandwidths and peak data rate per band 20/40 (2.4 GHz), 20/40/80/160 (5 GHz), 20/40/80/160/320 (6 GHz), and maximum peak data rate 28.8 Gbps
Wi-Fi antennaIntegrated down tilt omni‑directional antennas for 4×4 (2×2 on 2.4 GHz) MIMO. Built‑in antennas are optimized for horizontal ceiling mounted orientation of the AP. The down-tilt angle gain is roughly 30 to 40 degrees.
Click to view datasheet from HPE
