Dell PowerEdge R740 Configure to Order Server

Part Number: R740

The PowerEdge R740 was designed to accelerate application performance leveraging accelerator cards and storage scalability. The 2-socket, 2U platform has the optimum balance of resources to power the most demanding environments.

Expand and optimize application performance
The scalable business architecture of the R740 can scale up to three 300W or six 150W GPUs, or up to four FPGAs. With up to 16 2.5” drives or 8 3.5” drives the R740 provides the versatility to adapt to virtually any application and provides the perfect platform for VDI deployments.

  • Scale your VDI deployments with 3 double-width GPUs, supporting up to 50% more users when compared to R730.
  • Free up storage space using internal M.2 SSDs optimized for boot.
  • Scale compute resources with Intel® Xeon® Scalable delivering a 27% increase in processing cores and 50% increase in bandwidth over previous generation of Xeon processors.

Automate systems management with OpenManage
The Dell EMC OpenManage™ portfolio helps deliver peak efficiency for PowerEdge servers, delivering intelligent, automated management of routine tasks. Combined with unique agent-free management capabilities, the R740 is simply managed, freeing up time for high profile projects.

  • Simplify management with the New OpenManage Enterprise™ console, with customized reporting and automatic discovery.
  • Take advantage of QuickSync 2 capabilities and gain access to your servers easily through your phone or tablet

Rely on PowerEdge with built-in security
Every PowerEdge server is designed as part of a cyber resilient architecture, integrating security into the full server lifecycle. The R740 leverages new security features built-into every new PowerEdge server strengthening protection so you can reliably and securely deliver accurate data to your customers no matter where they are. By considering each aspect of system security, from design to retirement, Dell EMC ensures trust and delivers a worry-free, secure infrastructure without compromise.

  • Rely on a secure component supply chain to ensure protection from factory
    to the data center.
  • Maintain data safety with cryptographically signed firmware packages
    and Secure Boot.
  • Protect your server from malicious malware with iDRAC9 Server Lockdown mode
    (requires Enterprise or Datacenter license)
  • Wipe all data from storage media including hard drives, SSDs and system memory
    quickly and securely with System Erase



Processor
Up to two Intel® Xeon® Scalable processors, up to 28 cores per processor

Memory
24 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2666MT/s, 3TB max
Up to 12 NVDIMM, 192 GB Max
Supports registered ECC DDR4 DIMMs only

Storage controllers
Internal controllers: PERC H330, H730p, H740p, Software RAID (SWRAID) S140
Boot Optimized Storage Subsystem: HWRAID 2 x M.2 SSDs 120GB, 240 GB
External PERC (RAID): H840
12Gbps SAS HBAs (non-RAID): External- 12 Gbps SAS HBA (non-RAID), Internal- HBA330 (non-RAID)

Drive bays
Front drive bays: Up to 16 x 2.5” SAS/SATA (HDD/SSD) max 61TB or up to 8 x 3.5” SAS/SATA HDD max 96TB
Optional DVD-ROM, DVD+RW

Form factor
Rack (2U)

Power supplies
Titanium 750W, Platinum 495W, 750W,
750W 240VDC,2
1100W,
1100W 380VDC2
1600W, 2000W and 2400W, Gold 1100W -48VDC
Hot plug power supplies with full redundancy
Up to 6 hot plugs fans with full redundancy

Click to view full R740 Specs and Details from Dell

Complete our Request a Quote form or call us on 02 8424 3500 to buy your Poweredge R740s from Touchpoint.
