OnLogic Compact Fanless Industrial Coffee Lake Computer
Part Number: ML510G-50
FANLESS COFFEE LAKE PROCESSING
Intel’s latest Coffee Lake generation processor offers more cores and computational power in the same proven mini-ITX form factor. The ML510G-50 can be configured with up to 6 cores and 32 GB of DDR4 2666 MHz memory, making it a high-performance system with a fanless and compact footprint. The ML510G-50 is an ideal solution for compute-heavy applications as an industrial workstation, cloud aggregator, or edge server.
INDUSTRIAL DURABILITY
The ML510G-50 utilizes OnLogic’s own Hardshell Fanless Technology to ensure reliable computing that doesn’t quit. The removal of fans and the use of solid-state components eliminates the most common failure points, significantly increasing the lifespan of the system. Wall and DIN mounting options paired with industrial durability makes the ML510G-50 a versatile system that can handle a wide range of applications and environments.
FLEXIBLE I/O EXPANSION
Ready for a wide array of applications, dual Gb LAN, dual DisplayPort connectors, and six USB ports (four of them USB 3.1) make up the I/O base of the ML510G-50. Additional expansion options include 802.11ac Wi-Fi, CAN Bus, two additional LAN, up to four COM ports, and fast, reliable M.2 storage drives, giving the ML510G-50 incredible versatility.
| SKU | ML510G-50 |
|---|---|
| Hardware Line | Fanless Industrial |
| Cooling Type | Fanless |
| Processor Socket | LGA1151 |
| Processor Generation | Coffee Lake |
| Processor Cores | 2 4 6 |
| Chipset | Intel H310 |
| Graphics/GPU | Intel UHD Graphics 610 Intel UHD Graphics 630 |
| Memory Type | DDR4 SO-DIMM (non-ECC) |
| Memory Capacity | 32 GB |
| Memory Speed | 2400 MHz 2666 MHz |
| Memory Slot Count | 2.000000 |
| Number of Displays Supported | 2 |
| Rear I/O | 2 DisplayPort connectors 2 Gb LAN ports 4 USB 3.1 ports 2 Audio jacks (line-out; mic-in) |
| Front I/O | 2 USB 2.0 ports 4 COM ports (Optional) Power Button |
| Expansion Options | 1 M.2 E Key 2230 slot |
| Storage Options | 1 M.2 2280 SATA slot |
| LAN Controller | Intel I219V Realtek RTL8111H |
| System Monitoring | TPM (Optional) Watchdog Timer |
| Input Voltage | 19 VDC |
| Power Input | DC jack |
| Operating Temperature Range | 0 ~ 40°C 0 ~ 50°C (with certain configurations call us for more information) |
| Dimensions (WxHxD) | 197 x 86.2 x 202 mm 7.76″ x 3.41″ x 7.95″ |
| Case Type | Customizable Fanless Modular |
| Case Material | Aluminum Steel |
| Port Punchouts | 4 Antenna holes |
| Mounting Options | DIN-mount Wall-mount |
