Black Box FlexPoint Fast Ethernet (100-Mbps) Media Converter - 10/100-Mbps Copper to 100-Mbps Singlemode Fiber, 1310nm, 28km LMC100A-SM-R3

Part no: LMC100A-SM-R3

Black Box FlexPoint Fast Ethernet (100-Mbps) Media Converter – 10/100-Mbps Copper to 100-Mbps Singlemode Fiber, 1310nm, 28km LMC100A-SM-R3

Call for Details | Why Can't I See a Price?

Touchpoint can assist with new and refurbished equipment in most cases.

Request a Quote

  • We are a B2B sales organisation & do not sell to individual consumers.
  • We are located in Australia and in most cases will not be able to sell outside AU/NZ
  • This field is hidden when viewing the form
  • This field is hidden when viewing the form
  • This field is hidden when viewing the form

Black Box FlexPoint Fast Ethernet (100-Mbps) Media Converter – 10/100-Mbps Copper to 100-Mbps Singlemode Fiber, 1310nm, 28km

Part Number: LMC100A-SM-R3



  • Sends data up to 28 kilometers (17.3 mi.)
  • Complies with 10BASE-T, 100BASE-TX, and 100BASE-FX IEEE 802.3 standards
  • Both UTP and fiber ports support full- and half-duplex operation
  • UTP port autosenses 10- or 100-Mbps speeds
  • Manual override switch for extra control over fiber and UTP ports
  • Crossover switch provides easy connections to hubs or switches
  • Hardware available for mounting converter to a wall or a DIN rail
  • Metal housing has side vents
  • Can also be used in the FlexPoint 14-Slot Power Chassis or the FlexPoint 5-Position Rackmount Kit



General
CE Approval Yes
Power 110-VAC, 60-Hz, external power supply (230-VAC, 50-Hz version on request) or from the optional FlexPoint Power Chassis
Item Specifications
Connectors (1) 10-/100-Mbps Ethernet RJ-45, (1) pair ST
Dimensions 1″H x 3″W x 4″D (2.5 x 7.6 x 10.2 cm)
Weight 0.4 lb. (0.2 kg)
