CISCO (ASA5545-K9) ASA 5545-XWITH SW, 8GE DATA, 1GE MGMT, AC, 3DES/AES
Part Number: ASA5545-K9
Midsize businesses protecting the Internet edge require the same level of protection as large, enterprise networks. You require enterprise-strength security, but purchasing a firewall that was built to handle the performance needs and budget of a large enterprise would be unnecessary and a waste of company resources. You need a firewall that provides the performance you need at a price you can afford, without compromising security.
Brand
Cisco
Feature
VPN Support
General
Device Type
Security appliance
Height (Rack Units)
1U
Width
42.9 cm
Depth
48.4 cm
Height
4.2 cm
Weight
8.6 kg
Processor / Memory / Storage
RAM
12 GB
Networking
Form Factor
Rack-mountable
Ports Qty
14
Connectivity Technology
Wired
Data Link Protocol
Gigabit Ethernet
Performance
Firewall throughput: 3 Gbps VPN throughput (3DES/AES): 400 Mbps Connection rate: 30000 connections per second Firewall + intrusion prevention throughput: 900 Mbps
Capacity
IPSec VPN peers: 2500 SSL VPN peers: 2 Concurrent sessions: 750000 Virtual interfaces (VLANs): 300 Security contexts: 2
Status Indicators
Power, HDD activity, active, alarm
Features
Firewall protection, VPN support, VLAN support, High Availability
Encryption Algorithm
DES, Triple DES
Expansion / Connectivity
Expansion Slots
1 (total) / 0 (free) x expansion slot
Interfaces
14 x 1000Base-T – RJ-45 1 x 1000Base-T (management) – RJ-45 1 x management – RJ-45 2 x USB 2.0 – Type A
Miscellaneous
Rack Mounting Kit
Included
Compliant Standards
VCCI, C-Tick, EN 61000-3-2, ICES-003, EN 61000-3-3, EN55024, EN55022 Class A, CISPR 22, UL 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15 B Class A, CAN/CSA C22.2 No. 60950-1-07, ANSI C63.4-2009
Power
Power Device
Internal power supply
Installed Qty
2
Max Supported Qty
2
Power Redundancy
Yes
Voltage Required
AC 120/230 V (50/60 Hz)
Power Provided
400 Watt
Software / System Requirements
Software Included
Drivers & Utilities
Manufacturer Warranty
Service & Support
Limited warranty – 90 days
Environmental Parameters
Min Operating Temperature
-5 °C
Max Operating Temperature
40 °C
