Pegasus32 Series

NEW THUNDERBOLT™ 3 AND USB 3.2 GEN 2
HARDWARE RAID STORAGE FOR CREATIVE PROFESSIONALS

  • PromiseRAID engine renowned for performance, reliability and security.
  • Based on TitanRidge, Intel’s latest Thunderbolt™ chip, Pegasus32 has great new features expanding your connectivity.
  • Connect to either Thunderbolt™ 3 enabled host at 40Gbps or USB 3.2 Gen 2 enabled host at 10Gbps!
  • Thunderbolt™ 3 cable included
  • Supports 8K monitor via the full size 4-lane DP 1.4 port!
  • Power your hosts up to 85W with Thunderbolt™ 3
  • Up to 144TB of raw capacity with Pegasus32 R8
  • Read/Write speeds increase up to 2800 MB/s with SSD*
*Performance figures presented here are tested by PROMISE. Figures may vary by environment.

Massive Capacity and Extreme Performance

  • 18 Terabyte Hard Disk Drives (HDD) installed in the Pegasus32 R8 model, delivering a whopping 144 TB total storage capacity in the Pegasus32 R8.
  • High performance Solid State Drives (SSD) installed in Pegasus32 R8, increasing performance of the already extremely high performance RAID storage systems to levels unmatched by competing systems.

Multiple Displays

Dual Thunderbolt™ 3 ports use for daisy chain. High quality, reliable and quiet. Supports Kensington Lock. Promise SW Utility and cable included.3Y HW Warranty.



Up to 56TB
Over two hours of uncompressed 8K footage		 Up to 84TB
Best value for performance, protection, and capacity		 Up to 112TB
Highest capactiy and protection
Models Pegasus32 R4 Pegasus32 R6 Pegasus32 R8
Form Factor 4-Bay hardware RAID enclosure 6-Bay hardware RAID enclosure 8-Bay hardware RAID enclosure
Interface 2x USB-C ports either Thunderbolt™ 3 (40Gbps) or USB 3.2 Gen 2 (10Gbps)
RAID Level 0, 1, 5, 6, 10, JBOD 0, 1, 5, 6, 10, 50, JBOD 0, 1, 5, 6, 10, 50, 60, JBOD
Compatibility Enabled systems with macOS 10.14 or newer and Windows 10 x64
Capacity up to 56TB up to 84TB up to 112TB
Dimensions Height: 7.5 in / 19.2 cm
Width: 7.3 in / 18.7 cm
Length: 9.6 in / 24.5 cm		 Height: 9.8 in / 25.1 cm
Width: 7.3 in / 18.7 cm
Length: 9.6 in / 24.5 cm		 Height: 12.2 in / 31.0 cm
Width: 7.3 in / 18.7 cm
Length: 9.6 in / 24.5 cm
Weight 15 lb / 6.8 kg 20.1 lb / 9.1 kg 24.2 lb / 11 kg
Warranty 3-year warranty
Requirements Workstation or laptop with Thunderbolt™ 3 port or USB 3.2 port*



For more information on the Pegasus32 click here or contact us.
