OnLogic Neousys Rugged Intel Skylake Low Profile Fanless Computer
Part Number: NUVO-5000LP
A COMPACT INDUSTRIAL POWERHOUSE
Featuring 6th generation Intel Skylake processing, as well as RAID 0/1, support for 32GB of memory and 802.3at PoE capability with an 80W power budget, the Nuvo-5000LP is the perfect solution for processor-intensive applications such as machine vision, surveillance or industrial automation. The Nuvo-5000LP is also available with optional 4G LTE connectivity, enabling remote network access or failover protection.
READY FOR WORK
Protected within a low-profile, shock and vibration resistant enclosure, the Nuvo-5000LP offers numerous I/O configurations as well as wide voltage input and a wide operating temperature range. Complete with wall mounting hardware, or an optional DIN rail mount, the flexible Nuvo-5000LP can go anywhere.
CONNECT & CONQUER
With eight USB ports (four USB 3.0), three COM ports, and up to six LAN ports, the Nuvo-5000LP is ready to interface with the mix of modern and legacy systems common in today’s industrial and commercial work spaces. Offering VGA, DVI-D and dual DisplayPort connectors, the Nuvo-5000LP can accommodate simple analog video-out as well as 4K resolution or multiple simultaneous HD displays.
| SKU | Nuvo-5000LP |
|---|---|
| Hardware Line | Rugged |
| Cooling Type | Fanless |
| Processor Socket | LGA1151 |
| Processor Generation | Skylake |
| Chipset | Intel Q170 |
| Graphics/GPU | Intel HD Graphics 510 Intel HD Graphics 530 |
| Memory Type | DDR4 SO-DIMM (non-ECC) |
| Memory Capacity | 32 GB |
| Memory Slot Count | 2.000000 |
| Number of Displays Supported | 3 |
| Rear I/O | 4 USB 2.0 ports 2 RS-232/422/485 COM ports 1 RS-232 COM port 2 Audio jacks; mic-in, line-out 1 SIM card slot 1 3-pin terminal block power connector |
| Front I/O | 4 USB 3.2 Gen 1 ports 2 DisplayPort connectors 1 DVI-D port 1 VGA port 2 LAN ports (6 optional with Nuvo-5006LP) Power button Reset button |
| Expansion Options | 1 PCIe Mini Card (full height) |
| Storage Options | 2.5″ HDD/SSD 2.5″ Hot-swap HDD/SSD mSATA |
| RAID Support | 0/1 |
| LAN Controller | Intel I210 GbE Intel I219 GbE |
| System Monitoring | TPM 2.0 Support |
| Input Voltage | 8~35 VDC |
| Power Input | 3-pin Terminal Block connector |
| Operating Temperature Range | -25 ~ 70°C |
| Operating Humidity | 10% ~ 90% (non-condensing) |
| Shock Tolerance (Operating) | Operating, 50 Grms, Half-sine 11 ms Duration (w/ SSD, according to IEC60068-2-27) |
| Vibration Tolerance (Operating) | Operating, 5 Grms, 5-500 Hz, 3 Axes (w/ SSD, according to IEC60068-2-64) |
| Dimensions (WxHxD) | 240 x 77 x 225 mm 9.45″ x 3.03″ x 8.86″ |
| Case Type | Fanless Ruggedized |
| Case Material | Aluminum Extrusion Steel |
| Port Punchouts | 4 Antenna holes |
| Mounting Options | Wall-mount |
| Included Accessories | Wall mounting brackets |
